Product Details
Place of Origin: China
Brand Name: YESWITCH
Certification: IP68,CE,RoHS
Model Number: HT802DG1B4T1D23
Payment & Shipping Terms
Minimum Order Quantity: 500
Price: Negotiable
Packaging Details: Carton
Delivery Time: 4-6 Weeks
Payment Terms: T/T
Supply Ability: 7,000/Day
CONTACT RESISTANCE: |
20MΩ MAX(INITIAL) |
INSULATION RESISTANCE: |
100MΩ MIN/500VDC |
DIELECTRIC STRENGTH: |
1500VAC-1MINUTE |
MECHANICAL LIFE CYCLE: |
100.000 CYCLES |
OPERATING TEMPERATURE: |
-40 To +85 DEGREES |
FRONT SEAL: |
IP68 |
RESISTIVE LOAD: |
16A 125/250VAC,15A 28VDC |
INDUCTIVE LOAD: |
15A 28VDC |
LEVER: |
COPPER ALLOY |
MOVABLE CONTACT: |
COPPER ALLOY WITH SILVER |
VIBRATION STANDARD: |
MIL-STD-202F |
CONTACT RESISTANCE: |
20MΩ MAX(INITIAL) |
INSULATION RESISTANCE: |
100MΩ MIN/500VDC |
DIELECTRIC STRENGTH: |
1500VAC-1MINUTE |
MECHANICAL LIFE CYCLE: |
100.000 CYCLES |
OPERATING TEMPERATURE: |
-40 To +85 DEGREES |
FRONT SEAL: |
IP68 |
RESISTIVE LOAD: |
16A 125/250VAC,15A 28VDC |
INDUCTIVE LOAD: |
15A 28VDC |
LEVER: |
COPPER ALLOY |
MOVABLE CONTACT: |
COPPER ALLOY WITH SILVER |
VIBRATION STANDARD: |
MIL-STD-202F |
IP68 Rating Industrial Metal Toggle Switch With Solder Terminal For Heavy Equipment
| SPECIFICATIONS | |
| CONTACT RESISTANCE: | 20m ohm(Max) |
| INSULATION RESISTANCE: | 100VDC-100M ohm(Min) |
| DIELECTRIC STRENGTH: | 1500VAC-1MINUTE |
| MECHANICAL LIFE CYCLE: | 100.000 CYCLES |
| OPERATING TEMPERATURE: | -40 to +85 DEGREES |
| FRONT SEAL: | IP68 |
| RATING | |
| RESISTIVE LOAD: | 16A 125/250VAC,15A 28VDC |
| INDUCTIVE LOAD: | 15A 28VDC |
| MATERIAL | |
|
ACTUATOR: |
COPPER ALLOY |
|
HOUSING: |
NYLON (UL94V-0) |
|
BUSHING: |
ZINC ALLOY |
|
TERMINAL: |
COPPER ALLOY |
|
CONTACT: |
COPPER ALLOY |
|
O-RING: |
SILICONE RUBBER |
|
SHEEL: |
STAINLESS STELL |
Built for the rugged demands of heavy equipment, this ON-ON industrial metal toggle switch delivers reliable dual-position control, making it ideal for applications requiring seamless switching between two circuits. Its robust metal construction ensures exceptional durability, withstanding impacts, vibration, and extreme temperatures commonly encountered in construction, agriculture, and mining machinery. Whether controlling auxiliary lights, hydraulic systems, or alternate power sources, this switch maintains consistent performance in harsh environments where reliability is non-negotiable.
The flat metal handle is engineered for both functionality and longevity, offering a sturdy grip that facilitates precise operation—even when wearing thick work gloves. Its low-profile design minimizes the risk of accidental activation, a critical safety feature in high-activity work zones, while the clear ON-ON positioning ensures operators can quickly verify circuit status. Complemented by PC terminals, the switch provides secure, high-conductivity connections that resist corrosion and ensure stable current flow. These terminals simplify wiring integration, accommodating various wire sizes and maintaining tight connections to prevent voltage drops or interruptions.
Beyond its core functionality, this toggle switch meets stringent industrial standards, undergoing rigorous testing to validate its endurance, electrical stability, and resistance to environmental contaminants. It seamlessly integrates into existing electrical systems, supporting high-current loads without compromising safety or efficiency. From heavy-duty trucks to industrial cranes, this ON-ON toggle switch with a flat metal handle and PC terminals stands as a dependable solution, combining rugged construction, intuitive operation, and reliable performance for the most demanding heavy equipment applications.
FAQ
Q1: When can I get the quotation ?
A: We are online all day, so you can get quotation within 24h.
Q2: When can I get the samples?
A: It depends on the express, generally 3-10 days.
Q3: Can you accept small order?
A: Yes, we will try our best to help you with your business.
Q4: What's the lead time of mass production?
A: Generally 2-4weeks. We will inform you the delivery time after receiving your payment.
