Product Details
Place of Origin: China
Brand Name: YESWITCH
Certification: IP68,CE,RoHS
Model Number: HT802SG1B3T1D22
Payment & Shipping Terms
Minimum Order Quantity: 500
Price: Negotiable
Packaging Details: Carton
Delivery Time: 4-6 Weeks
Payment Terms: T/T
Supply Ability: 7,000/Day
CONTACT RESISTANCE: |
20MΩ MAX(INITIAL) |
INSULATION RESISTANCE: |
100MΩ MIN/500VDC |
DIELECTRIC STRENGTH: |
1500VAC-1MINUTE |
MECHANICAL LIFE CYCLE: |
100.000 CYCLES |
OPERATING TEMPERATURE: |
-40 To +85 DEGREES |
FRONT SEAL: |
IP68 |
RESISTIVE LOAD: |
16A 125/250VAC,15A 28VDC |
INDUCTIVE LOAD: |
15A 28VDC |
LEVER: |
COPPER ALLOY |
HOUSING: |
NYLON (UL94V-0) |
VIBRATION STANDARD: |
MIL-STD-202F |
CONTACT RESISTANCE: |
20MΩ MAX(INITIAL) |
INSULATION RESISTANCE: |
100MΩ MIN/500VDC |
DIELECTRIC STRENGTH: |
1500VAC-1MINUTE |
MECHANICAL LIFE CYCLE: |
100.000 CYCLES |
OPERATING TEMPERATURE: |
-40 To +85 DEGREES |
FRONT SEAL: |
IP68 |
RESISTIVE LOAD: |
16A 125/250VAC,15A 28VDC |
INDUCTIVE LOAD: |
15A 28VDC |
LEVER: |
COPPER ALLOY |
HOUSING: |
NYLON (UL94V-0) |
VIBRATION STANDARD: |
MIL-STD-202F |
Yellow Handle Industrial Metal Toggle Switch 5A 28VDC For Heavy Machinery
| SPECIFICATIONS | |
| CONTACT RESISTANCE: | 20m ohm(Max) |
| INSULATION RESISTANCE: | 100VDC-100M ohm(Min) |
| DIELECTRIC STRENGTH: | 1500VAC-1MINUTE |
| MECHANICAL LIFE CYCLE: | 100.000 CYCLES |
| OPERATING TEMPERATURE: | -40 to +85 DEGREES |
| FRONT SEAL: | IP68 |
| RATING | |
| RESISTIVE LOAD: | 16A 125/250VAC,15A 28VDC |
| INDUCTIVE LOAD: | 15A 28VDC |
| MATERIAL | |
|
ACTUATOR: |
COPPER ALLOY |
|
HOUSING: |
NYLON (UL94V-0) |
|
BUSHING: |
ZINC ALLOY |
|
TERMINAL: |
COPPER ALLOY |
|
CONTACT: |
COPPER ALLOY |
|
O-RING: |
SILICONE RUBBER |
|
SHEEL: |
STAINLESS STELL |
This industrial metal toggle switch stands out with its high-visibility yellow handle, designed for quick identification in cluttered heavy machinery control panels—ideal for operators needing to locate critical switches instantly, even in low-light or high-stress environments. Rated for 5A at 28VDC, it delivers precise, low-current control for auxiliary systems in construction equipment, mining trucks, and agricultural machinery, such as lighting, sensors, or secondary actuators.
Crafted from rugged metal alloy, the switch’s housing and handle resist corrosion, impact, and extreme temperatures (-40°C to 85°C), ensuring durability in dusty, muddy, or wet work sites. The yellow handle is powder-coated with a UV-resistant finish, retaining its bright color and visibility over years of exposure to sunlight and harsh chemicals.
Its compact design fits standard 12mm mounting holes, integrating seamlessly into existing control setups. The internal mechanism features a crisp, tactile toggle action, preventing accidental activation and ensuring reliable switching between ON/OFF positions. This precision reduces the risk of operational errors, a critical safety feature in heavy machinery operations.
Equipped with secure terminal connections, the switch maintains stable conductivity under constant vibration—common in heavy machinery—minimizing voltage drop and ensuring consistent performance. It meets standards, guaranteeing compliance with global safety regulations for industrial electrical components.
Whether controlling warning lights, cabin fans, or diagnostic systems, this switch combines high visibility, rugged construction, and precise electrical performance, making it an essential component for heavy machinery control systems.
FAQ
Q1: When can I get the quotation ?
A: We are online all day, so you can get quotation within 24h.
Q2: When can I get the samples?
A: It depends on the express, generally 3-10 days.
Q3: Can you accept small order?
A: Yes, we will try our best to help you with your business.
Q4: What's the lead time of mass production?
A: Generally 2-4weeks. We will inform you the delivery time after receiving your payment.
