5A steel toggle switch
, 28V steel toggle switch
, SS on on on toggle switch
5A 28V Anti-misoperation Switch Metal Switch With Outer Screw Terminal
| SPECIFICATION |
| CONTACT RESISTANCE: | 20m ohm(Max) |
| INSULATION RESISTANCE: | 100VDC-100M ohm(Min) |
| DIELECTRIC STRENGTH: | 1500VAC-1MINUTE |
| MECHANICAL LIFE CYCLE: | 100.000 CYCLES |
| OPERATING TEMPERATURE: | -40 to +85 DEGREES |
| FRONT SEAL: | IP68 |
| RATING |
| RESISTIVE LOAD: | 16A 125/250VAC,15A 28VDC |
| INDUCTIVE LOAD: | 15A 28VDC |
MATERIAL |
ACTUATOR: | COPPER ALLOY |
HOUSING: | NYLON (UL94V-0) |
BUSHING: | ZINC ALLOY |
TERMINAL: | COPPER ALLOY |
CONTACT: | COPPER ALLOY |
O-RING: | SILICONE RUBBER |
SHEEL: | STAINLESS STELL |
This high-reliability metal toggle switch is designed for precise control in low-voltage applications, featuring an anti-misoperation design and secure outer screw terminals for robust electrical connections. Ideal for industrial equipment, vehicles, and control panels where accidental switching must be prevented.
Key Features:
5A 28V DC Rating
The 5A 28V DC rating signifies a device’s capability to safely handle direct current at 28 volts with a 5-ampere current limit. Engineered for precision, it integrates heavy-gauge conductors and heat-resistant insulators to prevent overheating, while surge protection safeguards against voltage spikes. Ideal for aerospace, robotics, or industrial systems requiring stable DC power delivery within strict electrical parameters.
Anti-Misoperation Design
The Anti-Misoperation Design incorporates fail-safe mechanisms to prevent accidental or incorrect use. It may include interlocks, keyed switches, or sensor-activated safeguards that require deliberate actions, reducing human error. Ergonomic layouts and clear operational indicators further enhance safety in critical systems.
Durable Metal Housing
The Durable Metal Housing is constructed from high-strength alloys like aluminum or stainless steel, ensuring exceptional resistance to impact, corrosion, and extreme environmental conditions. Its rugged design features reinforced corners, welded seams, and a powder-coated finish to fend off scratches, rust, and chemical damage.
Outer Screw Terminals
The Outer Screw Terminals feature externally accessible threaded connectors for easy wiring and maintenance. Crafted from corrosion-resistant brass or stainless steel, they securely fasten wires with adjustable torque, ensuring stable electrical contact. Ideal for quick installations, their exposed design allows tool-free access, enhancing convenience in field applications or retrofits.
SPST/SPDT Configurations
SPST (Single Pole, Single Throw) and SPDT (Single Pole, Double Throw) configurations offer versatile switching solutions. SPST switches manage a single circuit with an on/off function, while SPDT directs current to one of two circuits. Both feature durable contacts for reliable conductivity in industrial or electronic setups.
Applications:
Industrial control panels
Automotive and marine electrical systems
Low-voltage power distribution
Machinery and equipment requiring anti-misoperation safety
Our Company
Yeswitch Electronics Co,.ltd, found in 1995, is one of the professional manufacturers of switches in Taiwan. We are specializing in manufacturing all kinds of switches, including metal switches, seat safety switches, key switches, push button switches,toggle switches, rocker switches,etc.
Yeswitch have supply all kinds of switches to global market with the good quality and competitive price. In recent years, we has expanded our product line from industrial products to consumer goods, catering the need for safety, practicality, and penalization. Customized services are also available upon request.
FAQ
Q1: When can I get the quotation ?
A: We are online all day, so you can get quotation within 24h.
Q2: When can I get the samples?
A: It depends on the express, generally 3-10 days.
Q3: Can you accept small order?
A: Yes, we will try our best to help you with your business.
Q4: What's the lead time of mass production?
A: Generally 2-4weeks. We will inform you the delivery time after receiving your payment.
