Product Details
Place of Origin: China
Brand Name: YESWITCH
Certification: IP68,CE,RoHS
Model Number: HT802DG3B7T1D24
Payment & Shipping Terms
Minimum Order Quantity: 500
Price: Negotiable
Packaging Details: Carton
Delivery Time: 4-6 Weeks
Payment Terms: T/T
Supply Ability: 7,000/Day
CONTACT RESISTANCE: |
20MΩ MAX(INITIAL) |
INSULATION RESISTANCE: |
100MΩ MIN/500VDC |
DIELECTRIC STRENGTH: |
1500VAC-1MINUTE |
MECHANICAL LIFE CYCLE: |
100.000 CYCLES |
OPERATING TEMPERATURE: |
-40 To +85 DEGREES |
FRONT SEAL: |
IP68 |
RESISTIVE LOAD: |
16A 125/250VAC,15A 28VDC |
INDUCTIVE LOAD: |
15A 28VDC |
LEVER: |
COPPER ALLOY |
HOUSING: |
NYLON (UL94V-0) |
TERMINAL: |
COPPER ALLOY |
VISUAL EXAMINATION: |
BY VISUAL EXAMINATION CHECK |
RESISTANCE HUMIDITY TIME: |
96 HOURS |
WAVE SOLDERING TEMPERATURE: |
260±5C |
CONTACT RESISTANCE: |
20MΩ MAX(INITIAL) |
INSULATION RESISTANCE: |
100MΩ MIN/500VDC |
DIELECTRIC STRENGTH: |
1500VAC-1MINUTE |
MECHANICAL LIFE CYCLE: |
100.000 CYCLES |
OPERATING TEMPERATURE: |
-40 To +85 DEGREES |
FRONT SEAL: |
IP68 |
RESISTIVE LOAD: |
16A 125/250VAC,15A 28VDC |
INDUCTIVE LOAD: |
15A 28VDC |
LEVER: |
COPPER ALLOY |
HOUSING: |
NYLON (UL94V-0) |
TERMINAL: |
COPPER ALLOY |
VISUAL EXAMINATION: |
BY VISUAL EXAMINATION CHECK |
RESISTANCE HUMIDITY TIME: |
96 HOURS |
WAVE SOLDERING TEMPERATURE: |
260±5C |
| Attribute | Value |
|---|---|
| CONTACT RESISTANCE | 20MΩ MAX(INITIAL) |
| INSULATION RESISTANCE | 100MΩ MIN/500VDC |
| DIELECTRIC STRENGTH | 1500VAC-1MINUTE |
| MECHANICAL LIFE CYCLE | 100.000 CYCLES |
| OPERATING TEMPERATURE | -40 to +85 DEGREES |
| FRONT SEAL | IP68 |
| RESISTIVE LOAD | 16A 125/250VAC,15A 28VDC |
| INDUCTIVE LOAD | 15A 28VDC |
| LEVER | COPPER ALLOY |
| HOUSING | NYLON (UL94V-0) |
| TERMINAL | COPPER ALLOY |
| VISUAL EXAMINATION | BY VISUAL EXAMINATION CHECK |
| RESISTANCE HUMIDITY TIME | 96 HOURS |
| WAVE SOLDERING TEMPERATURE | 260±5C |
This industrial metal toggle switch is engineered for extreme durability, featuring an IP68 ingress protection rating to withstand prolonged submersion in water and total resistance to dust, making it ideal for harsh environments like manufacturing plants, outdoor machinery, and marine applications.
Constructed with a rugged metal handle, it delivers exceptional strength against impact, corrosion, and wear, ensuring consistent operation even after repeated use. The precision-machined handle offers a firm, tactile feel, enabling easy actuation even with gloves.
Equipped with high-quality PC terminals, the switch ensures secure, low-resistance electrical connections, minimizing voltage drop and enhancing conductivity for reliable performance in high-current circuits. The terminals are designed for quick, tool-free installation, reducing assembly time and maintenance costs.
With a wide operating temperature range of -40°C to 85°C, this switch maintains functionality in extreme cold and heat. It meets international safety standards, including CE and RoHS compliance, guaranteeing safe operation in industrial systems.
Whether controlling motors, pumps, or heavy-duty equipment, this toggle switch combines robust construction with superior performance, making it a trusted choice for demanding industrial environments.
A: We are online all day, so you can get quotation within 24h.
A: It depends on the express, generally 3-10 days.
A: Yes, we will try our best to help you with your business.
A: Generally 2-4weeks. We will inform you the delivery time after receiving your payment.
